规格:
连接器类型 | 适配器类型 | 工作频率 | 插入损耗 | 驻波比 |
2.94mm | 2.94 female to female | up to 40ghz | 0.25db | <1.15 |
2.4mm | 2.4 female to female | up to 50ghz | 0.28db | <1.2 |
1.85mm | 1.85 female to female | up to 67ghz | 0.35db | <1.25 |
规格:
连接器类型 | 适配器类型 | 工作频率 | 插入损耗 | 驻波比 |
2.94mm | 2.94 female to female | up to 40ghz | 0.25db | <1.15 |
2.4mm | 2.4 female to female | up to 50ghz | 0.28db | <1.2 |
1.85mm | 1.85 female to female | up to 67ghz | 0.35db | <1.25 |
